Waterproof RFID Epoxy Resin Crystal Key Tag for Loyalty Cards

Shot Description:

Waterproof RFID Epoxy Resin Crystal Key Tag for Loyalty Cards Compressive casting by refined mould, antiseptic and high temperature resistance material. Encapsulating with chips and coils filled with epoxy resin. The different style of key ring card is soldering and assembling by ultrasonic wave. 1. Can choose color according to customers’ request , and can be designed and made according to the appearance offered by customer. 2. The inner can be…

Description:

Compressive casting by refined mould, antiseptic and high temperature resistance material. Encapsulating with chips and coils filled with epoxy resin. The different style of key ring card is soldering and assembling by ultrasonic wave.

1. Can choose color according to customers’ request , and can be designed and made according to the appearance offered by customer. 2. The inner can be encapsulated with different version of high and low frequency chip, can be compositely encapsulated. 3. The surface can be marked with icon, inkjet coding, ID code, serial number. 4. With the feature of dustproof, waterproof, anti-corrosion, anti-vibration. 5 Small and exquisite appearance, solid and durable, will not fade. 6. With key ring buckle, easy to take, can be made to PVC plastic card, epoxy or encapsulating chips and used for entrance guard, public transportation, parking, identity authentication, attendance management, skiing, entrance ticket, all-purpose card payment, product identification and so on.

Feature:

1. Easy for using, waterproof, dampproof, Anti-vibration, and high temperature esistance.

2. Additional Craft: Engraving, Embossing, Logo printed, Laser numbering, barcode, etc

3. Chip types: Low Frequency, High Frequency, Ultra-high Frequency

4. Color: Green, Yellow, Pink, Red, Blue etc

5. Shape: Flower, Animal, Cartoon Characters etc

6. Printing: Silkscreen, offset printing.

Product Name	RFID Epoxy Card Tag
Material	PVC + Epoxy resin
Craft	Ultrasonic welding , Glossy , Chip encoding , Series number
Dimension	52*32mm
Printing	CMYK offset printing
Operation Frequency	125Khz / 13.56 Mhz
Reading Distance	1 – 10 cm (Depend on the chip , working environment and the reader)
Data Retention	More than 10 years
Operating cycle	Can be read and encoding with more than 100,000 times
Working Temperature	-20°C~ +75°C
